• Wide range 342...528 V AC supply for operation on 380 V, 400 V or 480 V grids

• US 208 V models available

• High efficiency up to 95.5%

• Output power rating: 30 kW per device, expandable up to 1920 kW

• Output voltages: 60 V up to 2000 V

• Output currents: 40 A up to 1000 A

• Flexible, power regulated output stage

• Various protection circuits (OVP, OCP, OPP, OTP)

• 5" TFT touch panel with display for values, status and notifications

• Remote sensing with automatic detection

• Galvanically isolated interfaces (USB, Ethernet, analog)

• Integrated function generator with photovoltaics array simulation, including EN 50530

• Internal resistance simulation and regulation

• 60 V models compliant to SELV

• Discharge circuit (Uout < 60 V in ≤ 10 s)

• Optional, digital interface modules

• SCPI and ModBus RTU/TCP command set

• LabView VIs and control software for Windows

Options

• Digital interface modules for RS232, CAN, CANopen, ModBus TCP, Profibus, Profinet or EtherCAT (also see page 144.

• Water-cooling (also see page 150)

產(chǎn)品datasheet：
datasheet_psi10000_en.pdf

產(chǎn)品操作手冊(cè):

06230800_CN.pdf
