• Wide range 342...528 V AC supply for operation on 380 V, 400 V or 480 V grids

• US 208 V models available

• Bidirectional device - power supply and electronic load in one

• Energy recovery with high efficiency

• Power rating: 30 kW (15 kW*) per device, expandable up to 1920 kW

• Voltage ratings: 60 V up to 2000 V

• Current ratings: 40 A up to 1000 A

• Flexible, power regulated DC

• Various protection circuits (OVP, OCP, OPP, OTP)


• 5" TFT touch panel with display for values, status and notifications

• Remote sensing with automatic detection

• Galvanically isolated interfaces (USB, Ethernet, analog, slot)

• Integrated function generator

• Battery test, MPP tracking simulation, PV simulation according to EN 50530

• Optional, digital interface modules

• SCPI and ModBus command set

• LabView VIs and control software for Windows

• Digital interface modules for RS232, CAN, CANopen, ModBus TCP, Profibus, Profinet or EtherCAT. The interface slot is located on the rear panel, making it easy for the user to plug in a new interface or to re-place an existing one (also see page 144)

• Water-cooling (also see page 150)

• Grid protection & supervision module EA-ENS2 (only for 400 V supply, also see page 151)
